TensorFlow深度神经网络与图神经网络构建

卷积神经网络是目前深度学习的核心网络结构，被广泛的应用于计算机图像识别。

输入数据会通过多个卷积层及激活函数来获得输入数据的特征，每层之间的传递如下图：

在上面的图例中，每一个输入层的一格对应卷积层的四格，也可以更多。当然，一个输入层往往对应了很多个卷积层，比如RGB图片就有三个输入层，R图层，G图层与B图层，然后输入到大于3层或小于3层或刚好3层的卷积层中。卷积层后往往会有池化层，比如每2X2的格子里挑出最大的一个值出来，完成池化层后继续输入到新的卷积层中，再是池化层，再是卷积层…这样构成深度学习的网络，最后输出数据特征。

接下来上代码，先随意下载一些图片，比如猫和狗的图片，想分类什么都可以试试。

读取图片的函数，我下载了一些待分类的图片，一类放在set1文件夹，另一类放在set2文件夹：

登录后复制

import tensorflow as tf
import numpy as np
import glob


def load_data(my_label="set1"):

    def read_pic(pic_path):
        image_raw_data = tf.gfile.FastGFile(pic_path, 'rb').read()
        img_data = tf.image.decode_jpeg(image_raw_data)
        img_data = img_data.eval（).reshape(100, 100, 3)   # 所有图片都需要转换成相同大小
        return img_data.eval（)/255.0   # 图片数值控制在0到1之间，方便训练

    # 用glob模块获取图片路径
    paths = glob.glob("./%s/*.png" % my_label)
    if my_label == "set1":
        my_label = [0, 1]
    elif my_label == "set2":
        my_label = [1, 0]
    # 分成测试集和训练集
    pictures = []
    pictures_test = []
    labels = []
    labels_test = []
    check_num = 0
    for path in paths:
        check_num += 1
        if check_num % 2 == 0:
            pictures_test.append(read_pic(path))
            labels_test.append(my_label)
        else:
            pictures.append(read_pic(path))
            labels.append(my_label)
    return pictures, labels, pictures_test, labels_test

def datas():
    # 处理得粗狂了一些，生成set1及set2所有的数据。建议先转换好保存成数据直接读取，不然调参时每次转换图片过于耗时
    pictures, labels, pictures_test, labels_test = load_data("set1")
    pictures1, labels1, pictures_test1, labels_test1 = load_data("set2")
    pictures = np.array(pictures+pictures1)
    pictures_test = np.array(pictures_test+pictures_test1)
    labels = np.array(labels+labels1)
    labels_test = np.array(labels_test+labels_test1)
    print(np.shape(pictures), np.shape(pictures_test)) # 打印看下数据是什么样子
    print(np.shape(labels), np.shape(labels_test))
    return pictures, labels, pictures_test, labels_test



接下来就是CNN网络了，先定义输入的数据shape，输出节点数等:

登录后复制

INPUT_SHAPE = [None, 100, 100, 3]
OUTPUT_NODE = 2
TRAIN_STEP = 3000

定义变量weights及biases：

def weight_variable(shape):
    with tf.name_scope('weights'):
        Weights = tf.Variable(tf.random_normal(shape, stddev=0.1))
    return Weights

def biases_variable(shape):
    with tf.name_scope('biases'):
        Biases = tf.Variable(tf.random_normal(shape, mean=0.1, stddev=0.1))
    return Biases



卷积神经网络由卷积层，池化层及最后的全连接层构成，所以需要定义这三种，首先是卷积层，这里的striders是定义的在卷积层上的扫描模式，第一和第四位都是1，第二位和第三位代表水平方向和竖直方向一次跳多少格，另外可以对输出层周围进行填充，'SAME’就是不填充，'VALID’是第一列第一行都加一行:

登录后复制

def conv_layer(layername, inputs, Weights_shape, biases_shape, strides=[1, 1, 1, 1],
padding='VALID', activation_function=None):
    # add one more layer and return the output of this layer
    with tf.name_scope(layername):
        Weights = weight_variable(Weights_shape)
        biases = biases_variable(biases_shape)
        with tf.name_scope("h_conv"):
            h_conv = tf.nn.bias_add(tf.nn.conv2d(inputs, Weights,
            strides=strides, padding=padding), biases)
        if activation_function is None:
            outputs = h_conv
        else:
            outputs = activation_function(h_conv)
    return outputs



然后是池化层，ksize是在2X2内处理，strides也和卷积层的意义一样，这里默认每次跳两格

登录后复制

def pool_layer(layername, conv, ksize=[1, 2, 2, 1], strides=[1, 2, 2, 1],
padding='SAME', pooling_function=None):
with tf.name_scope(layername):
if pooling_function is None:
outputs = conv
else:
outputs = pooling_function(conv, ksize=ksize, strides=strides, padding=padding)
return outputs



最后是需要全连接层来降低维数，减少节点数

登录后复制

def fc_layer(layername, inputs, Weights_shape, biases_shape, activation_function=None):
    with tf.name_scope(layername):
        Weights = weight_variable(Weights_shape)
        biases = biases_variable(biases_shape)
        with tf.name_scope('Wx_plus_b'):
            Wx_plus_b = tf.matmul(inputs, Weights) + biases
        if activation_function is None:
            outputs = Wx_plus_b
        else:
            outputs = activation_function(Wx_plus_b, name = layername)
        tf.summary.histogram(layername+"/outputs", outputs)
    return outputs



各种层都定义好了就可以写卷积神经网络的模型了，这里写一个简单一点的，输入层-卷积层-池化层-卷积层-池化层-全连接层

登录后复制

def mode(inputs, keep_prob):
    # 需要计算好每层会有多少个节点
    # 我的输入层为[None, 100, 100, 3]，以2X2的大小进行卷积，第一个卷积层从3层对应到48层，
    权重的第四个值应该是和偏差的个数相同
    # 每一层卷积层是使用relu函数
    conv1_layer1 = conv_layer("conv1_layer1", inputs, [2, 2, 3, 48], [48],
    [1, 1, 1, 1], 'SAME', tf.nn.relu)
    # 池化层1，每2X2的格子里挑出最大值
    pool1_layer2 = pool_layer("pooling1_layer2", conv1_layer1, [1, 2, 2, 1],
    [1, 2, 2, 1], 'VALID', tf.nn.max_pool)
    # 第二层卷积层
    conv2_layer3 = conv_layer("conv2_layer3", pool1_layer2, [2, 2, 48, 96],
    [96], [1, 1, 1, 1], 'SAME', tf.nn.relu)
    # 第二层池化层
    pool2_layer4 = pool_layer("pooling2_layer4", conv2_layer3, [1, 2, 2, 1],
     [1, 2, 2, 1], 'VALID', tf.nn.max_pool)
    layer4_shape = pool2_layer4.get_shape().as_list()
    print(layer4_shape)
    # 将数据降维，并用全连接层降低节点数目
    pool2_layer4flat = tf.reshape(pool2_layer4,
    [-1, layer4_shape[1]*layer4_shape[2]*layer4_shape[3]])
    fc1_layer5 = fc_layer("fc1_layer5",
    pool2_layer4flat, [layer4_shape[1]*layer4_shape[2]*layer4_shape[3], 50], [50], tf.nn.relu)
    # 训练过程中随机扔掉一些节点，防止过拟合
    fc1_layer5_drop = tf.nn.dropout(fc1_layer5, keep_prob)
    # 最后通过一个全连接层输出结果
    fc2_layer6 = fc_layer("fc2_layer6", fc1_layer5_drop, [50, output_node], [output_node])
    return fc2_layer6



然后需要定义损失函数

登录后复制

def loss(outputs, outputs_target, learning_rate=0.001, Optimizer = "Adam"):
    end_points = {}
    # 计算交叉熵时，tf.log需要加上一个极小值，防止Nan出现
    cross_entropy = -tf.reduce_mean(outputs_target*tf.log(outputs+1e-10))
    if Optimizer == "Adam":
        train_step = tf.train.AdamOptimizer(learning_rate).minimize(cross_entropy)
    elif Optimizer == "GradientDescent":
        train_step = tf.train.GradientDescentOptimizer(learning_rate).minimize(cross_entropy)
    correct_prediction = tf.equal(tf.argmax(outputs, 1), tf.argmax(outputs_target, 1))
    accuracy = tf.reduce_mean(tf.cast(correct_prediction, tf.float32))
    end_points["accuracy"] = accuracy
    end_points["loss"] = cross_entropy
    end_points["train_step"] = train_step
    end_points["outputs"] = outputs
    end_points["outputs_target"] = outputs_target
    return end_points



训练的函数跟之前写的全连接神经网络的类似

登录后复制

def train():
    ##run tf
    x = tf.placeholder(tf.float32, INPUT_SHAPE, name="data")
    y_ = tf.placeholder(tf.float32, [None, OUTPUT_NODE], name="target")
    keep_prob = tf.placeholder(tf.float32, name="keep_prob")
    outputs = tf.nn.softmax(mode(x, keep_prob), name="op_to_store")
    end_points = loss(outputs, y_, 0.035, "GradientDescent")
    init_op = tf.group(tf.global_variables_initializer(), tf.local_variables_initializer())
    saver = tf.train.Saver()
    with tf.Session() as sess:
        pictures, labels, pictures_test, labels_test = datas()
        sess.run(init_op)
        merged = tf.summary.merge_all()
        writer = tf.summary.FileWriter("./cnv_tbgragh", sess.graph)
        for i in range(0, TRAIN_STEP):
            _, loss_ = sess.run([end_points["train_step"], end_points["loss"]],
            feed_dict={x: pictures, y_: labels, keep_prob: 0.5})
            print (i, loss_)
        saver.save(sess, "./model.ckpt")
        loss_, accuracy_, test_y, true_y = sess.run([\
                        end_points["loss"], end_points["accuracy"], end_points["outputs"],
                        end_points["outputs_target"]], \
                        feed_dict={x: pictures_test, y_: labels_test, keep_prob: 1.0})
        print(accuracy_)
        print(test_y.tolist(), true_y.tolist())



下面贴上完整的代码：

登录后复制

# -*- coding: utf-8 -*-

import tensorflow as tf
import numpy as np
import glob


def load_data(my_label="set1"):

    def read_pic(pic_path):
        image_raw_data = tf.gfile.FastGFile(pic_path, 'rb').read()
        img_data = tf.image.decode_jpeg(image_raw_data)
        img_data = img_data.eval（).reshape(100, 100, 3)   # 所有图片都需要转换成相同大小
        return img_data.eval（)/255.0   # 图片数值控制在0到1之间，方便训练

    paths = glob.glob("./%s/*.png" % my_label)
    if my_label == "set1":
        my_label = [0, 1]
    elif my_label == "set2":
        my_label = [1, 0]
    # 分成测试集和训练集
    pictures = []
    pictures_test = []
    labels = []
    labels_test = []
    check_num = 0
    for path in paths:
        check_num += 1
        if check_num % 2 == 0:
            pictures_test.append(read_pic(path))
            labels_test.append(my_label)
        else:
            pictures.append(read_pic(path))
            labels.append(my_label)
    return pictures, labels, pictures_test, labels_test

def datas():
    # 处理得粗狂了一些，生成set1及set2所有的数据。建议先转换好保存成数据直接读取，不然调参时每次转换图片过于耗时
    pictures, labels, pictures_test, labels_test = load_data("set1")
    pictures1, labels1, pictures_test1, labels_test1 = load_data("set2")
    pictures = np.array(pictures+pictures1)
    pictures_test = np.array(pictures_test+pictures_test1)
    labels = np.array(labels+labels1)
    labels_test = np.array(labels_test+labels_test1)
    print(np.shape(pictures), np.shape(pictures_test)) # 打印看下数据是什么样子
    print(np.shape(labels), np.shape(labels_test))
    return pictures, labels, pictures_test, labels_test

----------------------------------------------------

INPUT_SHAPE = [None, 100, 100, 3]
OUTPUT_NODE = 2
TRAIN_STEP = 3000

def weight_variable(shape):
    with tf.name_scope('weights'):
        Weights = tf.Variable(tf.random_normal(shape, stddev=0.1))
    return Weights

def biases_variable(shape):
    with tf.name_scope('biases'):
        Biases = tf.Variable(tf.random_normal(shape, mean=0.1, stddev=0.1))
    return Biases

def conv_layer(layername, inputs, Weights_shape, biases_shape, strides=[1, 1, 1, 1],
padding='VALID', activation_function=None):
    # add one more layer and return the output of this layer
    with tf.name_scope(layername):
        Weights = weight_variable(Weights_shape)
        biases = biases_variable(biases_shape)
        with tf.name_scope("h_conv"):
            h_conv = tf.nn.bias_add(tf.nn.conv2d(inputs, Weights, strides=strides,
            padding=padding), biases)
        if activation_function is None:
            outputs = h_conv
        else:
            outputs = activation_function(h_conv)
    return outputs

def pool_layer(layername, conv, ksize=[1, 2, 2, 1], strides=[1, 2, 2, 1],
padding='SAME', pooling_function=None):
    with tf.name_scope(layername):
        if pooling_function is None:
            outputs = conv
        else:
            outputs = pooling_function(conv, ksize=ksize, strides=strides, padding=padding)
    return outputs

def fc_layer(layername, inputs, Weights_shape, biases_shape, activation_function=None):
    with tf.name_scope(layername):
        Weights = weight_variable(Weights_shape)
        biases = biases_variable(biases_shape)
        with tf.name_scope('Wx_plus_b'):
            Wx_plus_b = tf.matmul(inputs, Weights) + biases
        if activation_function is None:
            outputs = Wx_plus_b
        else:
            outputs = activation_function(Wx_plus_b, name = layername)
        tf.summary.histogram(layername+"/outputs", outputs)
    return outputs

def mode(inputs, keep_prob):
    conv1_layer1 = conv_layer("conv1_layer1", inputs, [2, 2, 3, 48],
    [48], [1, 1, 1, 1], 'SAME', tf.nn.relu)
    pool1_layer2 = pool_layer("pooling1_layer2", conv1_layer1,
    [1, 2, 2, 1], [1, 2, 2, 1], 'VALID', tf.nn.max_pool)
    conv2_layer3 = conv_layer("conv2_layer3", pool1_layer2,
    [2, 2, 48, 96], [96], [1, 1, 1, 1], 'SAME', tf.nn.relu)
    pool2_layer4 = pool_layer("pooling2_layer4", conv2_layer3,
     [1, 2, 2, 1], [1, 2, 2, 1], 'VALID', tf.nn.max_pool)
    layer4_shape = pool2_layer4.get_shape().as_list()
    # print(layer4_shape)
    pool2_layer4flat = tf.reshape(pool2_layer4,
    [-1, layer4_shape[1]*layer4_shape[2]*layer4_shape[3]])
    fc1_layer5 = fc_layer("fc1_layer5", pool2_layer4flat,
    [layer4_shape[1]*layer4_shape[2]*layer4_shape[3], 50], [50], tf.nn.relu)
    fc1_layer5_drop = tf.nn.dropout(fc1_layer5, keep_prob)
    fc2_layer6 = fc_layer("fc2_layer6", fc1_layer5_drop, [50, output_node], [output_node])
    return fc2_layer6

def loss(outputs, outputs_target, learning_rate=0.001, Optimizer = "Adam"):
    end_points = {}
    # 计算交叉熵时，tf.log需要加上一个极小值，防止Nan出现
    cross_entropy = -tf.reduce_mean(outputs_target*tf.log(outputs+1e-10))
    if Optimizer == "Adam":
        train_step = tf.train.AdamOptimizer(learning_rate).minimize(cross_entropy)
    elif Optimizer == "GradientDescent":
        train_step = tf.train.GradientDescentOptimizer(learning_rate).minimize(cross_entropy)
    correct_prediction = tf.equal(tf.argmax(outputs, 1), tf.argmax(outputs_target, 1))
    accuracy = tf.reduce_mean(tf.cast(correct_prediction, tf.float32))
    end_points["accuracy"] = accuracy
    end_points["loss"] = cross_entropy
    end_points["train_step"] = train_step
    end_points["outputs"] = outputs
    end_points["outputs_target"] = outputs_target
    return end_points

def train():
    ##run tf
    x = tf.placeholder(tf.float32, INPUT_SHAPE, name="data")
    y_ = tf.placeholder(tf.float32, [None, OUTPUT_NODE], name="target")
    keep_prob = tf.placeholder(tf.float32, name="keep_prob")
    outputs = tf.nn.softmax(mode(x, keep_prob), name="op_to_store")
    end_points = loss(outputs, y_, 0.035, "GradientDescent")
    init_op = tf.group(tf.global_variables_initializer(),
    tf.local_variables_initializer())
    saver = tf.train.Saver()
    with tf.Session() as sess:
        pictures, labels, pictures_test, labels_test = datas()
        sess.run(init_op)
        merged = tf.summary.merge_all()
        writer = tf.summary.FileWriter("./model_tbgragh", sess.graph)
        for i in range(0, TRAIN_STEP):
            _, loss_ = sess.run([end_points["train_step"], end_points["loss"]],
            feed_dict={x: pictures, y_: labels, keep_prob: 0.5})
            print (i, loss_)
        saver.save(sess, "./model.ckpt")
        loss_, accuracy_, test_y, true_y = sess.run([\
                        end_points["loss"], end_points["accuracy"],
                        end_points["outputs"], end_points["outputs_target"]], \
                        feed_dict={x: pictures_test, y_: labels_test, keep_prob: 1.0})
        print(accuracy_)
        print(test_y.tolist(), true_y.tolist())

def main(_):
    train()

if __name__ == "__main__":
    tf.app.run()



另外需要说明的是，如果电脑内存不够16g不要随意运行，有一个正经一点的服务器最好，训练图片4000张左右会用到10g以上的内存，当然也可以把图片大小再改小一点，如果只想试试CNN，就少整一些图片。

免责声明：本文系网络转载或改编，未找到原创作者，版权归原作者所有。如涉及版权，请联系删
