TensorFlow实战：线性回归模型入门

首先导入各种TensorFlow等工具及设置画图的大小及字体

登录后复制

import numpy as npimport tensorflow as tfimport matplotlib.pyplot as pltplt
.rcParams['figure.figsize'] = (10.0, 8.0)plt.rcParams['font.sans-serif'] = 'NSimSun,
Times New Roman'1.2.3.4.5.

生成用于进行线性回归的模型的数据

登录后复制

# 随机生成100个点，围绕在y=3x+5的直线周围num_points = 200vectors_set = []for i in range(num_points):
x1 = np.random.uniform(-10, 25)    y1 = x1 * 3 + 5 + np.random.normal(0.0, 5)
vectors_set.append([x1, y1])# 生成一些样本x_data = [v[0] for v in
vectors_set]y_data = [v[1] for v in vectors_set]
plt.scatter(x_data,y_data,c='r')plt.show()1.2.3.4.5.6.7.8.9.10.11.12.

生成的数据及画出的点像图如下：

设置模型的原始数据，编写现行回归的训练模型代码，并使用梯度下降算法进行训练

登录后复制

W = tf.Variable(tf.random_uniform([1], -1.0, 1.0), name='W')b = tf.Variable(tf.zeros([1]),
name='b')y = W * x_data + bloss = tf.reduce_mean(tf.square(y - y_data), name='loss')
optimizer = tf.train.GradientDescentOptimizer(0.005)train =
optimizer.minimize(loss, name='train')sess = tf.Session()init = tf.
global_variables_initializer()sess.run(init)# 初始化的W和b是多少print ("W =", sess.run(W),
"\tb =", sess.run(b), "\tloss =", sess.run(loss))# 执行20次训练for step in range(1000):
sess.run(train)    # 输出训练好的W和b    if(step % 50 == 0):
print ("W =", sess.run(W), "\tb =", sess.run(b), "\tloss =",
sess.run(loss))print ("最终的结果 W =", sess.run(W), "\tb =", sess.run(b),
"\tloss =", sess.run(loss))1.2.3.4.5.6.7.8.9.10.11.12.13.14.15.16.17.18.

训练过程显示的参数结果如下：

W = [ 0.26262569]  b = [ 0.]  loss = 1366.89
W = [ 4.73117256]  b = [ 0.23248257]  loss = 386.389
W = [ 3.15473843]  b = [ 1.66317821]  loss = 32.05
W = [ 3.10857034]  b = [ 2.7120173]  loss = 27.6106
W = [ 3.07622719]  b = [ 3.44677091]  loss = 25.432
W = [ 3.05356979]  b = [ 3.96149445]  loss = 24.3628
W = [ 3.03769755]  b = [ 4.32207775]  loss = 23.8381
W = [ 3.02657843]  b = [ 4.57468128]  loss = 23.5806
W = [ 3.01878905]  b = [ 4.7516408]  loss = 23.4542
W = [ 3.01333213]  b = [ 4.87560892]  loss = 23.3922
W = [ 3.00950956]  b = [ 4.96245146]  loss = 23.3617
W = [ 3.00683141]  b = [ 5.02328825]  loss = 23.3468
W = [ 3.00495553]  b = [ 5.06590843]  loss = 23.3395
W = [ 3.00364113]  b = [ 5.09576511]  loss = 23.3359
W = [ 3.00272036]  b = [ 5.11667919]  loss = 23.3341
W = [ 3.00207567]  b = [ 5.13133097]  loss = 23.3332
W = [ 3.00162363]  b = [ 5.14159679]  loss = 23.3328
W = [ 3.00130725]  b = [ 5.14878702]  loss = 23.3326
W = [ 3.00108552]  b = [ 5.15382385]  loss = 23.3325
W = [ 3.00093007]  b = [ 5.15735531]  loss = 23.3324
W = [ 3.00082135]  b = [ 5.1598258]  loss = 23.3324
最终的结果 W = [ 3.00074625]  b = [ 5.16152811]  loss = 23.3324

登录后复制

plt.scatter(x_data,y_data,c='r')plt.plot(x_data,sess.run(W)*x_data+sess.run(b))plt.show()1.2.3.
