Python实现人脸检测与对齐的教程

最近在实现Pairwise Relational Networks for Face Recognition论文，预处理人脸时发现资料没那么好找，现整理成jupyter文档方便回顾。预处理的总体流程：人脸关键点检测

根据眼部关键点旋转图片做人脸对齐

旋转人脸关键点，使其与对齐后的图片匹配

根据关键点裁剪人脸到固定尺寸(此步骤和PRN论文略有不同)

变换人脸关键点，使其与裁剪后的图片匹配

1 Imports

import cv2

import numpy as np

import math

from collections import defaultdict

from PIL import Image,ImageDraw

from matplotlib.pyplot import imshow

%matplotlib inline

import matplotlib.pyplot as plt

import face_recognition # install from https://github.com/ageitgey/face_recognition

2 导入图片

img_name = '/home/dataset/face_recognize/lfw_test/Aishwarya_Rai/Aishwarya_Rai_0001.jpg'

image_array = cv2.imread(img_name)

Image.fromarray(image_array)

3 人脸检测

使用face_recognition api检测人脸的关键点， model=”large”时返回68个关键点， model=”small”时返回5个关键点。

face_landmarks_list = face_recognition.face_landmarks(image_array, model="large")

face_landmarks_dict = face_landmarks_list[0]

print(face_landmarks_dict, end=" ")

'''out{'chin': [(76, 102), (74, 115), (72, 128), (70, 142), (73, 155), (80, 165), (90, 175), (102, 183), (114, 188), (126, 189), (136, 183), (145, 176), (152, 168), (159, 159), (164, 149), (167, 138), (169, 128)],'left_eyebrow': [(94, 93), (103, 90), (113, 90), (122, 94), (129, 100)],'right_eyebrow': [(147, 105), (155, 104), (162, 104), (168, 108), (171, 114)],'nose_bridge': [(136, 113), (135, 121), (134, 129), (133, 137)],'nose_tip': [(119, 137), (123, 140), (128, 144), (133, 144), (137, 143)],'left_eye': [(102, 105), (109, 105), (115, 107), (119, 111), (113, 110), (107, 108)],'right_eye': [(145, 119), (152, 118), (157, 119), (161, 123), (156, 123), (151, 121)],'top_lip': [(99, 146), (109, 144), (119, 145), (125, 148), (131, 148), (138, 152), (142, 159), (139, 158), (130, 154), (124, 153), (118, 150), (101, 147)], 'bottom_lip': [(142, 159), (134, 168), (126, 170), (120, 168), (113, 166), (105, 159), (99, 146), (101, 147), (116, 159), (122, 161), (128, 162), (139, 158)]}'''

定义人脸关键点可视化函数

def visualize_landmark(image_array, landmarks):

""" plot landmarks on image:param image_array: numpy array of a single image:param landmarks: dict of landmarks for facial parts as keys and tuple of coordinates as values:return: plots of images with landmarks on"""

origin_img = Image.fromarray(image_array)

draw = ImageDraw.Draw(origin_img)

for facial_feature in landmarks.keys():

draw.point(landmarks[facial_feature])

imshow(origin_img)

可视化人脸关键点

visualize_landmark(image_array=image_array,landmarks=face_landmarks_dict)

plt.show()

4 人脸对齐

4.1 人脸旋转对齐

人脸对齐思路：分别计算左、右眼中心坐标

计算左右眼中心坐标连线与水平方向的夹角θ

计算左右两眼整体中心坐标

以左右两眼整体中心坐标为基点，将图片array逆时针旋转θ

以下定义了人脸对齐函数

def align_face(image_array, landmarks):

""" align faces according to eyes position:param image_array: numpy array of a single image:param landmarks: dict of landmarks for facial parts as keys and tuple of coordinates as values:return:rotated_img: numpy array of aligned imageeye_center: tuple of coordinates for eye centerangle: degrees of rotation"""

# get list landmarks of left and right eye

left_eye = landmarks['left_eye']

right_eye = landmarks['right_eye']

# calculate the mean point of landmarks of left and right eye

left_eye_center = np.mean(left_eye, axis=0).astype("int")

right_eye_center = np.mean(right_eye, axis=0).astype("int")

# compute the angle between the eye centroids

dy = right_eye_center[1] - left_eye_center[1]

dx = right_eye_center[0] - left_eye_center[0]

# compute angle between the line of 2 centeroids and the horizontal line

angle = math.atan2(dy, dx) * 180. / math.pi

# calculate the center of 2 eyes

eye_center = ((left_eye_center[0] + right_eye_center[0]) // 2,

(left_eye_center[1] + right_eye_center[1]) // 2)

# at the eye_center, rotate the image by the angle

rotate_matrix = cv2.getRotationMatrix2D(eye_center, angle, scale=1)

rotated_img = cv2.warpAffine(image_array, rotate_matrix, (image_array.shape[1], image_array.shape[0]))

return rotated_img, eye_center, angle

根据眼睛位置旋转整个图片，达到人脸对齐的目的。下图可以看出，旋转后图片(右图)中的人脸一对齐，双眼在水平方向上。align_face函数输出的eye_center, angle会在章节4.2张使用到。

aligned_face, eye_center, angle = align_face(image_array=image_array, landmarks=face_landmarks_dict)

Image.fromarray(np.hstack((image_array,aligned_face)))

4.2 人脸关键点旋转

图片旋转后，图中的landmark坐标也要相应旋转，这样landmark才能匹配旋转后的图片。landmark旋转前的效果如下：

visualize_landmark(image_array=aligned_face,landmarks=face_landmarks_dict)

plt.show()

定义旋转图片中坐标的函数，具体公式推导见平面内直角坐标系中坐标旋转变换公式 - Eric_Wangyz的博客 - CSDN博客。另，由于图片和普通坐标系的原点不同，两者坐标点的旋转方式略有出入，图片坐标旋转涉及y坐标在图片坐标系和普通坐标系之间的变换，

def rotate(origin, point, angle, row):

""" rotate coordinates in image coordinate system:param origin: tuple of coordinates,the rotation center:param point: tuple of coordinates, points to rotate:param angle: degrees of rotation:param row: row size of the image:return: rotated coordinates of point"""

x1, y1 = point

x2, y2 = origin

y1 = row - y1

y2 = row - y2

angle = math.radians(angle)

x = x2 + math.cos(angle) * (x1 - x2) - math.sin(angle) * (y1 - y2)

y = y2 + math.sin(angle) * (x1 - x2) + math.cos(angle) * (y1 - y2)

y = row - y

return int(x), int(y)

定义旋转图片中landmark的函数，以人脸双眼中心为基点，将每个人脸关键点逆时针旋转θ，该θ角度是人脸对齐的旋转角度。

def rotate_landmarks(landmarks, eye_center, angle, row):

""" rotate landmarks to fit the aligned face:param landmarks: dict of landmarks for facial parts as keys and tuple of coordinates as values:param eye_center: tuple of coordinates for eye center:param angle: degrees of rotation:param row: row size of the image:return: rotated_landmarks with the same structure with landmarks, but different values"""

rotated_landmarks = defaultdict(list)

for facial_feature in landmarks.keys():

for landmark in landmarks[facial_feature]:

rotated_landmark = rotate(origin=eye_center, point=landmark, angle=angle, row=row)

rotated_landmarks[facial_feature].append(rotated_landmark)

return rotated_landmarks

以下旋转所有人脸关键点，并可视化。

rotated_landmarks = rotate_landmarks(landmarks=face_landmarks_dict,

eye_center=eye_center, angle=angle, row=image_array.shape[0])

visualize_landmark(image_array=aligned_face,landmarks=rotated_landmarks)

plt.show()

5 人脸裁剪

通常，人脸对齐后会根据landmark裁剪人脸到固定尺寸，再feed近卷积网络。此处裁剪的思路为：水平方向以最靠左和最靠右的landmark的中点为裁剪后图片的中心点

垂直方向上分为三部分中部：两眼landmark中心到嘴巴landmark中心的像素距离

底部和顶部：(size-两眼landmark中心到嘴巴landmark中心的距离)/2，size为输入高度

定义裁剪函数

def corp_face(image_array, size, landmarks):

""" crop face according to eye,mouth and chin position:param image_array: numpy array of a single image:param size: single int value, size for w and h after crop:param landmarks: dict of landmarks for facial parts as keys and tuple of coordinates as values:return:cropped_img: numpy array of cropped imageleft, top: left and top coordinates of cropping"""

x_min = np.min(landmarks['chin'], axis=0)[0]

x_max = np.max(landmarks['chin'], axis=0)[0]

x_center = (x_max - x_min) / 2 + x_min

left, right = (x_center - size / 2, x_center + size / 2)

eye_landmark = landmarks['left_eye'] + landmarks['right_eye']

eye_center = np.mean(eye_landmark, axis=0).astype("int")

lip_landmark = landmarks['top_lip'] + landmarks['bottom+lip']

lip_center = np.mean(lip_landmark, axis=0).astype("int")

mid_part = lip_center[1] - eye_center[1]

top, bottom = eye_center[1] - (size - mid_part) / 2, lip_center[1] + (size - mid_part) / 2

pil_img = Image.fromarray(image_array)

left, top, right, bottom = [int(i) for i in [left, top, right, bottom]]

cropped_img = pil_img.crop((left, top, right, bottom))

cropped_img = np.array(cropped_img)

return cropped_img, left, top

人脸裁剪后，大小变成了140 * 140。

cropped_face, left, top = corp_face(image_array=aligned_face, size=140, landmarks=rotated_landmarks)

Image.fromarray(cropped_face)

定义landmark变换函数，由于图片裁剪，landmark坐标需要再次变换。

def transfer_landmark(landmarks, left, top):

"""transfer landmarks to fit the cropped face:param landmarks: dict of landmarks for facial parts as keys and tuple of coordinates as values:param left: left coordinates of cropping:param top: top coordinates of cropping:return: transferred_landmarks with the same structure with landmarks, but different values"""

transferred_landmarks = defaultdict(list)

for facial_feature in landmarks.keys():

for landmark in landmarks[facial_feature]:

transferred_landmark = (landmark[0] - left, landmark[1] - top)

transferred_landmarks[facial_feature].append(transferred_landmark)

return transferred_landmarks

landmark坐标变换后完美fit裁剪后的人脸。

transferred_landmarks = transfer_landmark(landmarks=rotated_landmarks, left=left, top=top)

visualize_landmark(image_array=cropped_face,landmarks=transferred_landmarks)

plt.show()

======================= 更新 =======================

6 人脸裁剪逻辑修改

应知友需求，修改人脸裁剪逻辑以适应不同尺寸的输入图片，调整后的人脸裁剪逻辑和PRN论文一致：垂直方向上分为三部分中部：两眼landmark中心到嘴巴landmark中心的像素距离，占垂直方向的35%

底部：占垂直方向的35%

顶部：占垂直方向的30%

水平方向以最靠左和最靠右的landmark的中点为裁剪后图片的中心点，crop区域w=h

def corp_face(image_array, landmarks):

""" crop face according to eye,mouth and chin position:param image_array: numpy array of a single image:param landmarks: dict of landmarks for facial parts as keys and tuple of coordinates as values:return:cropped_img: numpy array of cropped image"""

eye_landmark = np.concatenate([np.array(landmarks['left_eye']),

np.array(landmarks['right_eye'])])

eye_center = np.mean(eye_landmark, axis=0).astype("int")

lip_landmark = np.concatenate([np.array(landmarks['top_lip']),

np.array(landmarks['bottom_lip'])])

lip_center = np.mean(lip_landmark, axis=0).astype("int")

mid_part = lip_center[1] - eye_center[1]

top = eye_center[1] - mid_part * 30 / 35

bottom = lip_center[1] + mid_part

w = h = bottom - top

x_min = np.min(landmarks['chin'], axis=0)[0]

x_max = np.max(landmarks['chin'], axis=0)[0]
