CPS8E 8-node biquadratic plane stress piezoelectric quadrilateral (Abaqus Analysis User's Manual Section 22.1.3)
CPS8R 8-node biquadratic plane stress quadrilateral, reduced integration (Abaqus Analysis User's Manual Section 22.1.3)
CPS8RE 8-node biquadratic plane stress piezoelectric quadrilateral, reduced integration (Abaqus Analysis User's Manual Section 22.1.3)
CPS8RT 8-node plane stress thermally coupled quadrilateral, biquadratic displacement, bilinear temperature, reduced integration (Abaqus Analysis User's Manual Section 22.1.3)
CPS8T 8-node plane stress thermally coupled quadrilateral, biquadratic displacement, bilinear temperature (Abaqus Analysis User's Manual Section 22.1.3)
DASHPOT1 Dashpot between a node and ground, acting in a fixed direction (Abaqus Analysis User's Manual Section 26.2.2)
DASHPOT2 Dashpot between two nodes, acting in a fixed direction (Abaqus Analysis User's Manual Section 26.2.2)
DASHPOTA Axial dashpot between two nodes, whose line of action is the line joining the two nodes (Abaqus Analysis User's Manual Section 26.2.2)
DC1D2 2-node heat transfer link (Abaqus Analysis User's Manual Section 22.1.2)
DC1D2E 2-node coupled thermal-electrical link (Abaqus Analysis User's Manual Section 22.1.2)
DC1D3 3-node heat transfer link (Abaqus Analysis User's Manual Section 22.1.2)
DC1D3E 3-node coupled thermal-electrical link (Abaqus Analysis User's Manual Section 22.1.2)
DC2D3 3-node linear heat transfer triangle (Abaqus Analysis User's Manual Section 22.1.3)
DC2D3E 3-node linear coupled thermal-electrical triangle (Abaqus Analysis User's Manual Section 22.1.3)
DC2D4 4-node linear heat transfer quadrilateral (Abaqus Analysis User's Manual Section 22.1.3)
DC2D4E 4-node linear coupled thermal-electrical quadrilateral (Abaqus Analysis User's Manual Section 22.1.3)
DC2D6 6-node quadratic heat transfer triangle (Abaqus Analysis User's Manual Section 22.1.3)
DC2D6E 6-node quadratic coupled thermal-electrical triangle (Abaqus Analysis User's Manual Section 22.1.3)
DC2D8 8-node quadratic heat transfer quadrilateral (Abaqus Analysis User's Manual Section 22.1.3)
DC2D8E 8-node quadratic coupled thermal-electrical quadrilateral (Abaqus Analysis User's Manual Section 22.1.3)
DC3D4 4-node linear heat transfer tetrahedron (Abaqus Analysis User's Manual Section 22.1.4)
DC3D4E 4-node linear coupled thermal-electrical tetrahedron (Abaqus Analysis User's Manual Section 22.1.4)
DC3D6 6-node linear heat transfer triangular prism (Abaqus Analysis User's Manual Section 22.1.4)
DC3D6E 6-node linear coupled thermal-electrical triangular prism (Abaqus Analysis User's Manual Section 22.1.4)
DC3D8 8-node linear heat transfer brick (Abaqus Analysis User's Manual Section 22.1.4)
DC3D8E 8-node linear coupled thermal-electrical brick (Abaqus Analysis User's Manual Section 22.1.4)
DC3D10 10-node quadratic heat transfer tetrahedron (Abaqus Analysis User's Manual Section 22.1.4)
DC3D10E 10-node quadratic coupled thermal-electrical tetrahedron (Abaqus Analysis User's Manual Section 22.1.4)
DC3D15 15-node quadratic heat transfer triangular prism (Abaqus Analysis User's Manual Section 22.1.4)
DC3D15E 15-node quadratic coupled thermal-electrical triangular prism (Abaqus Analysis User's Manual Section 22.1.4)
DC3D20 20-node quadratic heat transfer brick (Abaqus Analysis User's Manual Section 22.1.4)
DC3D20E 20-node quadratic coupled thermal-electrical brick (Abaqus Analysis User's Manual Section 22.1.4)
DCAX3 3-node linear axisymmetric heat transfer triangle (Abaqus Analysis User's Manual Section 22.1.6)
DCAX3E 3-node linear axisymmetric coupled thermal-electrical triangle (Abaqus Analysis User's Manual Section 22.1.6)
DCAX4 4-node linear axisymmetric heat transfer quadrilateral (Abaqus Analysis User's Manual Section 22.1.6)
DCAX4E 4-node linear axisymmetric coupled thermal-electrical quadrilateral (Abaqus Analysis User's Manual Section 22.1.6)
DCAX6 6-node quadratic axisymmetric heat transfer triangle (Abaqus Analysis User's Manual Section 22.1.6)
DCAX6E 6-node quadratic axisymmetric coupled thermal-electrical triangle (Abaqus Analysis User's Manual Section 22.1.6)
DCAX8 8-node quadratic axisymmetric heat transfer quadrilateral (Abaqus Analysis User's Manual Section 22.1.6)
DCAX8E 8-node quadratic axisymmetric coupled thermal-electrical quadrilateral (Abaqus Analysis User's Manual Section 22.1.6)
DCC1D2 2-node convection/diffusion link (Abaqus Analysis User's Manual Section 22.1.2)
DCC1D2D 2-node convection/diffusion link, dispersion control (Abaqus Analysis User's Manual Section 22.1.2)
DCC2D4 4-node convection/diffusion quadrilateral (Abaqus Analysis User's Manual Section 22.1.3)
DCC2D4D 4-node convection/diffusion quadrilateral, dispersion control (Abaqus Analysis User's Manual Section 22.1.3)
DCC3D8 8-node convection/diffusion brick (Abaqus Analysis User's Manual Section 22.1.4)
DCC3D8D 8-node convection/diffusion brick, dispersion control (Abaqus Analysis User's Manual Section 22.1.4)
DCCAX2 2-node axisymmetric convection/diffusion link (Abaqus Analysis User's Manual Section 22.1.6)
DCCAX2D 2-node axisymmetric convection/diffusion link, dispersion control (Abaqus Analysis User's Manual Section 22.1.6)
DCCAX4 4-node axisymmetric convection/diffusion quadrilateral (Abaqus Analysis User's Manual Section 22.1.6)
DCCAX4D 4-node axisymmetric convection/diffusion quadrilateral, dispersion control (Abaqus Analysis User's Manual Section 22.1.6)
DCOUP2D Two-dimensional distributing coupling element (Abaqus Analysis User's Manual Section 26.4.2)
DCOUP3D Three-dimensional distributing coupling element (Abaqus Analysis User's Manual Section 26.4.2)
DGAP Unidirectional thermal interactions between two nodes (Abaqus Analysis User's Manual Section 31.2.2)
DRAG2D 2-D drag chain, for use in cases where only horizontal motion is being studied (Abaqus Analysis User's Manual Section 26.12.2)
DRAG3D 3-D drag chain (Abaqus Analysis User's Manual Section 26.12.2)
DS3 3-node heat transfer triangular shell (Abaqus Analysis User's Manual Section 23.6.7)
DS4 4-node heat transfer quadrilateral shell (Abaqus Analysis User's Manual Section 23.6.7)
DS6 6-node heat transfer triangular shell (Abaqus Analysis User's Manual Section 23.6.7)
DS8 8-node heat transfer quadrilateral shell (Abaqus Analysis User's Manual Section 23.6.7)
DSAX1 2-node axisymmetric heat transfer shell (Abaqus Analysis User's Manual Section 23.6.9)
DSAX2 3-node axisymmetric heat transfer shell (Abaqus Analysis User's Manual Section 23.6.9)
ELBOW31 2-node pipe in space with deforming Abaqus Analysis User's Manual Section, linear interpolation along the pipe (Abaqus Analysis User's Manual Section 23.5.2)
ELBOW31B 2-node pipe in space with ovalization only, axial gradients of ovalization neglected (Abaqus Analysis User's Manual Section 23.5.2)
ELBOW31C 2-node pipe in space with ovalization only, axial gradients of ovalization neglected. This is the same as element type ELBOW31B except that the odd numbered terms in the Fourier interpolation around the pipe, except the first term, are neglected. (Abaqus Analysis User's Manual Section 23.5.2)
ELBOW32 3-node pipe in space with deforming Abaqus Analysis User's Manual Section, quadratic interpolation along the pipe (Abaqus Analysis User's Manual Section 23.5.2)
F2D2 2-node linear 2-D hydrostatic fluid element (Abaqus Analysis User's Manual Section 26.8.2)
F3D3 3-node linear 3-D triangular hydrostatic fluid element (Abaqus Analysis User's Manual Section 26.8.2)
F3D4 4-node linear 3-D quadrilateral hydrostatic fluid element (Abaqus Analysis User's Manual Section 26.8.2)
FAX2 2-node linear axisymmetric hydrostatic fluid element (Abaqus Analysis User's Manual Section 26.8.2)
FLINK 2-node linear fluid link (Abaqus Analysis User's Manual Section 26.8.4)
FRAME2D 2-node two-dimensional straight frame element (Abaqus Analysis User's Manual Section 23.4.3)
FRAME3D 2-node three-dimensional straight frame element (Abaqus Analysis User's Manual Section 23.4.3)
GAPCYL Cylindrical gap between two nodes (Abaqus Analysis User's Manual Section 31.2.2)
GAPSPHER Spherical gap between two nodes (Abaqus Analysis User's Manual Section 31.2.2)
GAPUNI Unidirectional gap between two nodes (Abaqus Analysis User's Manual Section 31.2.2)
GAPUNIT Unidirectional gap and thermal interactions between two nodes (Abaqus Analysis User's Manual Section 31.2.2)
GK2D2 2-node two-dimensional gasket element (Abaqus Analysis User's Manual Section 26.6.7)
GK2D2N 2-node two-dimensional gasket element with thickness-direction behavior only (Abaqus Analysis User's Manual Section 26.6.7)
GK3D2 2-node three-dimensional gasket element (Abaqus Analysis User's Manual Section 26.6.8)
GK3D2N 2-node three-dimensional gasket element with thickness-direction behavior only (Abaqus Analysis User's Manual Section 26.6.8)
GK3D4L 4-node three-dimensional line gasket element (Abaqus Analysis User's Manual Section 26.6.8)
GK3D4LN 4-node three-dimensional line gasket element with thickness-direction behavior only (Abaqus Analysis User's Manual Section 26.6.8)
GK3D6L 6-node three-dimensional line gasket element (Abaqus Analysis User's Manual Section 26.6.8)
GK3D6LN 6-node three-dimensional line gasket element with thickness-direction behavior only (Abaqus Analysis User's Manual Section 26.6.8)
GK3D6 6-node three-dimensional gasket element (Abaqus Analysis User's Manual Section 26.6.8)
GK3D6N 6-node three-dimensional gasket element with thickness-direction behavior only (Abaqus Analysis User's Manual Section 26.6.8)
GK3D8 8-node three-dimensional gasket element (Abaqus Analysis User's Manual Section 26.6.8)
GK3D8N 8-node three-dimensional gasket element with thickness-direction behavior only (Abaqus Analysis User's Manual Section 26.6.8)
GK3D12M 12-node three-dimensional gasket element (Abaqus Analysis User's Manual Section 26.6.8)
GK3D12MN 12-node three-dimensional gasket element with thickness-direction behavior only (Abaqus Analysis User's Manual Section 26.6.8)
GK3D18 18-node three-dimensional gasket element (Abaqus Analysis User's Manual Section 26.6.8)
GK3D18N 18-node three-dimensional gasket element with thickness-direction behavior only (Abaqus Analysis User's Manual Section 26.6.8)
GKAX2 2-node axisymmetric gasket element (Abaqus Analysis User's Manual Section 26.6.9)
GKAX2N 2-node axisymmetric gasket element with thickness-direction behavior only (Abaqus Analysis User's Manual Section 26.6.9)
GKAX4 4-node axisymmetric gasket element (Abaqus Analysis User's Manual Section 26.6.9)
GKAX4N 4-node axisymmetric gasket element with thickness-direction behavior only (Abaqus Analysis User's Manual Section 26.6.9)
GKAX6 6-node axisymmetric gasket element (Abaqus Analysis User's Manual Section 26.6.9)
GKAX6N 6-node axisymmetric gasket element with thickness-direction behavior only (Abaqus Analysis User's Manual Section 26.6.9)
GKPE4 4-node plane strain gasket element (Abaqus Analysis User's Manual Section 26.6.7)
GKPE6 6-node plane strain gasket element (Abaqus Analysis User's Manual Section 26.6.7)
GKPS4 4-node plane stress gasket element (Abaqus Analysis User's Manual Section 26.6.7)
GKPS4N 4-node two-dimensional gasket element with thickness-direction behavior only (Abaqus Analysis User's Manual Section 26.6.7)
GKPS6 6-node plane stress gasket element (Abaqus Analysis User's Manual Section 26.6.7)
GKPS6N 6-node two-dimensional gasket element with thickness-direction behavior only (Abaqus Analysis User's Manual Section 26.6.7)
HEATCAP Point heat capacitance (Abaqus Analysis User's Manual Section 24.4.2)
IRS21A Axisymmetric rigid surface element (for use with first-order axisymmetric elements) (Abaqus Analysis User's Manual Section 31.5.2)
IRS22A Axisymmetric rigid surface element (for use with second-order axisymmetric elements) (Abaqus Analysis User's Manual Section 31.5.2)
ISL21A 2-node axisymmetric slide line element (for use with first-order axisymmetric elements) (Abaqus Analysis User's Manual Section 31.4.2)
ISL22A 3-node axisymmetric slide line element (for use with second-order axisymmetric elements) (Abaqus Analysis User's Manual Section 31.4.2)
ITSCYL Cylindrical geometry tube support interaction element (Abaqus Analysis User's Manual Section 26.9.2)
ITSUNI Unidirectional tube support interaction element (Abaqus Analysis User's Manual Section 26.9.2)
ITT21 Tube-tube element for use with first-order, 2-D beam and pipe elements (Abaqus Analysis User's Manual Section 31.3.2)
ITT31 Tube-tube element for use with first-order, 3-D beam and pipe elements (Abaqus Analysis User's Manual Section 31.3.2)
JOINT2D Two-dimensional elastic-plastic joint interaction element. These elements are available only for use in Abaqus/Aqua. (Abaqus Analysis User's Manual Section 26.11.2)
JOINT3D Three-dimensional elastic-plastic joint interaction element. These elements are available only for use in Abaqus/Aqua. (Abaqus Analysis User's Manual Section 26.11.2)
JOINTC Three-dimensional joint interaction element (Abaqus Analysis User's Manual Section 26.3.2)
LS3S 3-node second-order line spring for use on a symmetry plane (Abaqus Analysis User's Manual Section 26.10.2)
LS6 6-node general second-order line spring. This element can be used only with linear elastic material behavior. (Abaqus Analysis User's Manual Section 26.10.2)
M3D3 3-node triangular membrane (Abaqus Analysis User's Manual Section 23.1.2)
M3D4 4-node quadrilateral membrane (Abaqus Analysis User's Manual Section 23.1.2)
M3D4R 4-node quadrilateral membrane, reduced integration, hourglass control (Abaqus Analysis User's Manual Section 23.1.2)
M3D6 6-node triangular membrane (Abaqus Analysis User's Manual Section 23.1.2)
M3D8 8-node quadrilateral membrane (Abaqus Analysis User's Manual Section 23.1.2)
M3D8R 8-node quadrilateral membrane, reduced integration (Abaqus Analysis User's Manual Section 23.1.2)
M3D9 9-node quadrilateral membrane (Abaqus Analysis User's Manual Section 23.1.2)
M3D9R 9-node quadrilateral membrane, reduced integration, hourglass control (Abaqus Analysis User's Manual Section 23.1.2)
MASS Point mass (Abaqus Analysis User's Manual Section 24.1.2)
MAX1 2-node linear axisymmetric membrane (Abaqus Analysis User's Manual Section 23.1.4)
MAX2 3-node quadratic axisymmetric membrane (Abaqus Analysis User's Manual Section 23.1.4)
MCL6 6-node cylindrical membrane (Abaqus Analysis User's Manual Section 23.1.3)
MCL9 9-node cylindrical membrane (Abaqus Analysis User's Manual Section 23.1.3)
MGAX1 2-node linear axisymmetric membrane, twist (Abaqus Analysis User's Manual Section 23.1.4)
MGAX2 3-node quadratic axisymmetric membrane, twist (Abaqus Analysis User's Manual Section 23.1.4)
PIPE21 2-node linear pipe in a plane (Abaqus Analysis User's Manual Section 23.3.8)
PIPE21H 2-node linear pipe in a plane, hybrid formulation (Abaqus Analysis User's Manual Section 23.3.8)
PIPE22 3-node quadratic pipe in a plane (Abaqus Analysis User's Manual Section 23.3.8)
PIPE22H 3-node quadratic pipe in a plane, hybrid formulation (Abaqus Analysis User's Manual Section 23.3.8)
PIPE31 2-node linear pipe in space (Abaqus Analysis User's Manual Section 23.3.8)
PIPE31H 2-node linear pipe in space, hybrid formulation (Abaqus Analysis User's Manual Section 23.3.8)
PIPE32 3-node quadratic pipe in space (Abaqus Analysis User's Manual Section 23.3.8)
PIPE32H 3-node quadratic pipe in space, hybrid formulation (Abaqus Analysis User's Manual Section 23.3.8)
PSI24 4-node 2-D pipe-soil interaction element (Abaqus Analysis User's Manual Section 26.13.2)
PSI26 6-node 2-D pipe-soil interaction element (Abaqus Analysis User's Manual Section 26.13.2)
PSI34 4-node 3-D pipe-soil interaction element (Abaqus Analysis User's Manual Section 26.13.2)
PSI36 6-node 3-D pipe-soil interaction element (Abaqus Analysis User's Manual Section 26.13.2)
R2D2 2-node 2-D linear rigid link (for use in plane strain or plane stress) (Abaqus Analysis User's Manual Section 24.3.2)
R3D3 3-node 3-D rigid triangular facet (Abaqus Analysis User's Manual Section 24.3.2)
R3D4 4-node 3-D bilinear rigid quadrilateral (Abaqus Analysis User's Manual Section 24.3.2)
RAX2 2-node linear axisymmetric rigid link (for use in axisymmetric planar geometries) (Abaqus Analysis User's Manual Section 24.3.2)
RB2D2 2-node 2-D rigid beam (Abaqus Analysis User's Manual Section 24.3.2)
RB3D2 2-node 3-D rigid beam (Abaqus Analysis User's Manual Section 24.3.2)
ROTARYI Rotary inertia at a point (Abaqus Analysis User's Manual Section 24.2.2)
S3 3-node triangular general-purpose shell, finite membrane strains (identical to element S3R) (Abaqus Analysis User's Manual Section 23.6.7)
S3T 3-node thermally coupled triangular general-purpose shell, finite membrane strains (identical to element S3RT) (Abaqus Analysis User's Manual Section 23.6.7)
S3R 3-node triangular general-purpose shell, finite membrane strains (identical to element S3) (Abaqus Analysis User's Manual Section 23.6.7)
S3RT 3-node thermally coupled triangular general-purpose shell, finite membrane strains (identical to element S3T) (Abaqus Analysis User's Manual Section 23.6.7)
S4 4-node doubly curved general-purpose shell, finite membrane strains (Abaqus Analysis User's Manual Section 23.6.7)
S4T 4-node thermally coupled doubly curved general-purpose shell, finite membrane strains (Abaqus Analysis User's Manual Section 23.6.7)
S4R 4-node doubly curved general-purpose shell, reduced integration, hourglass control, finite membrane strains (Abaqus Analysis User's Manual Section 23.6.7)
S4RT 4-node thermally coupled doubly curved general-purpose shell, reduced integration, hourglass control, finite membrane strains (Abaqus Analysis User's Manual Section 23.6.7)
S4R5 4-node doubly curved thin shell, reduced integration, hourglass control, using five degrees of freedom per node (Abaqus Analysis User's Manual Section 23.6.7)
S8R 8-node doubly curved thick shell, reduced integration (Abaqus Analysis User's Manual Section 23.6.7)
S8R5 8-node doubly curved thin shell, reduced integration, using five degrees of freedom per node (Abaqus Analysis User's Manual Section 23.6.7)
S8RT 8-node thermally coupled quadrilateral general thick shell, biquadratic displacement, bilinear temperature in the shell surface (Abaqus Analysis User's Manual Section 23.6.7)
S9R5 9-node doubly curved thin shell, reduced integration, using five degrees of freedom per node (Abaqus Analysis User's Manual Section 23.6.7)
SAX1 2-node linear axisymmetric thin or thick shell (Abaqus Analysis User's Manual Section 23.6.9)
SAX2 3-node quadratic axisymmetric thin or thick shell (Abaqus Analysis User's Manual Section 23.6.9)
SAX2T 3-node axisymmetric thermally coupled thin or thick shell, quadratic displacement, linear temperature in the shell surface (Abaqus Analysis User's Manual Section 23.6.9)
SAXA1N Linear asymmetric-axisymmetric, Fourier shell element with 2 nodes in the generator direction and N Fourier modes (Abaqus Analysis User's Manual Section 23.6.10)
SAXA2N Quadratic asymmetric-axisymmetric, Fourier shell element with 3 nodes in the generator direction and N Fourier modes (Abaqus Analysis User's Manual Section 23.6.10)
SC6R 6-node triangular in-plane continuum shell wedge, general-purpose continuum shell, finite membrane strains. (Abaqus Analysis User's Manual Section 23.6.8)
SC8R 8-node quadrilateral in-plane general-purpose continuum shell, reduced integration with hourglass control, finite membrane strains. (Abaqus Analysis User's Manual Section 23.6.8)
SC6RT 6-node linear displacement and temperature, triangular in-plane continuum shell wedge, general-purpose continuum shell, finite membrane strains. (Abaqus Analysis User's Manual Section 23.6.8)
SC8RT 8-node linear displacement and temperature, quadrilateral in-plane general-purpose continuum shell, reduced integration with hourglass control, finite membrane strains. (Abaqus Analysis User's Manual Section 23.6.8)
SFM3D3 3-node triangular surface element (Abaqus Analysis User's Manual Section 26.7.2)
SFM3D4 4-node quadrilateral surface element (Abaqus Analysis User's Manual Section 26.7.2)
SFM3D4R 4-node quadrilateral surface element, reduced integration (Abaqus Analysis User's Manual Section 26.7.2)
SFM3D6 6-node triangular surface element (Abaqus Analysis User's Manual Section 26.7.2)
SFM3D8 8-node quadrilateral surface element (Abaqus Analysis User's Manual Section 26.7.2)
SFM3D8R 8-node quadrilateral surface element, reduced integration (Abaqus Analysis User's Manual Section 26.7.2)
SFMAX1 2-node linear axisymmetric surface element (Abaqus Analysis User's Manual Section 26.7.4)
SFMAX2 3-node quadratic axisymmetric surface element (Abaqus Analysis User's Manual Section 26.7.4)
SFMCL6 6-node cylindrical surface element (Abaqus Analysis User's Manual Section 26.7.3)
SFMCL9 9-node cylindrical surface element (Abaqus Analysis User's Manual Section 26.7.3)
SFMGAX1 2-node linear axisymmetric surface element, twist (Abaqus Analysis User's Manual Section 26.7.4)
SFMGAX2 3-node quadratic axisymmetric surface element, twist (Abaqus Analysis User's Manual Section 26.7.4)
SPRING1 Spring between a node and ground, acting in a fixed direction (Abaqus Analysis User's Manual Section 26.1.2)
SPRING2 Spring between two nodes, acting in a fixed direction (Abaqus Analysis User's Manual Section 26.1.2)
SPRINGA Axial spring between two nodes, whose line of action is the line joining the two nodes. This line of action may rotate in large-displacement analysis. (Abaqus Analysis User's Manual Section 26.1.2)
STRI3 3-node triangular facet thin shell (Abaqus Analysis User's Manual Section 23.6.7)
STRI65 6-node triangular thin shell, using five degrees of freedom per node (Abaqus Analysis User's Manual Section 23.6.7)
T2D2 2-node linear 2-D truss (Abaqus Analysis User's Manual Section 23.2.2)
T2D2E 2-node 2-D piezoelectric truss (Abaqus Analysis User's Manual Section 23.2.2)
T2D2H 2-node linear 2-D truss, hybrid (Abaqus Analysis User's Manual Section 23.2.2)
T2D2T 2-node 2-D thermally coupled truss (Abaqus Analysis User's Manual Section 23.2.2)
T2D3 3-node quadratic 2-D truss (Abaqus Analysis User's Manual Section 23.2.2)
T2D3E 3-node 2-D piezoelectric truss (Abaqus Analysis User's Manual Section 23.2.2)
T2D3H 3-node quadratic 2-D truss, hybrid (Abaqus Analysis User's Manual Section 23.2.2)
T2D3T 3-node 2-D thermally coupled truss (Abaqus Analysis User's Manual Section 23.2.2)
T3D2 2-node linear 3-D truss (Abaqus Analysis User's Manual Section 23.2.2)
T3D2E 2-node 3-D piezoelectric truss (Abaqus Analysis User's Manual Section 23.2.2)
T3D2H 2-node linear 3-D truss, hybrid (Abaqus Analysis User's Manual Section 23.2.2)
T3D2T 2-node 3-D thermally coupled truss (Abaqus Analysis User's Manual Section 23.2.2)
T3D3 3-node quadratic 3-D truss (Abaqus Analysis User's Manual Section 23.2.2)
T3D3E 3-node 3-D piezoelectric truss (Abaqus Analysis User's Manual Section 23.2.2)
T3D3H 3-node quadratic 3-D truss, hybrid (Abaqus Analysis User's Manual Section 23.2.2)
T3D3T 3-node 3-D thermally coupled truss (Abaqus Analysis User's Manual Section 23.2.2)
WARP2D3 3-node linear 2-D warping element (Abaqus Analysis User's Manual Section 22.3.2)
WARP2D4 4-node bilinear 2-D warping element (Abaqus Analysis User's Manual Section 22.3.2)
WARPF2D3 3-node linear two-dimensional warping element with free (unconstrained) in-plane and out-of-plane warping
WARPF2D4 4-node bilinear two-dimensional warping element with free (unconstrained) in-plane and out-of-plane warping
WARPF2D6 6-node quadratic two-dimensional warping element with free (unconstrained) in-plane and out-of-plane warping
WARPF2D8 8-node quadratic two-dimensional warping element with free (unconstrained) in-plane and out-of-plane warping
免责声明：本文系网络转载或改编，未找到原创作者，版权归原作者所有。如涉及版权，请联系删
155-2731-8020
