Cadence Layout LVS时出现Error的解决方法

ERROR (OSSHNL-116): Unable to descend into any of the views defined in the view list, 'cdl schematic', for the

   instance 'M3' in cell 'ldo_amp_lowIQ'. Add one of these views to the cell 'n33' in the
library 'smic13mmrf_1233', or modify the view list so that it contains an existing view.

End netlisting Oct 26 11:28:48 2023

   ERROR (OSSHNL-514): Netlist generation failed because of the errors reported above. The netlist might not have been generated at all, or the generated netlist could be corrupt. Fix the reported errors and regenerate the netlist.

原因：网表导出错误。

解决 办法：

在启动 virtuoso 之前在terminal输入：

export  CDS_Netlisting_Mode=Analog

再重新启动virtuoso，跑lvs
